Department Of Mechanical Engineering

The Department of Mechanical Engineering is started in the year 2009, with affiliation from Anna University & Anna University of Technology. It currently offers Undergraduate degree(B.E) and having plan to offer Postgraduate degree. Department have talented mix of students (intake of 100% sanctioned strength in the first two batches) , technical staff and experienced (Both in Industry & teaching) faculty members. With over 120 students (undergraduate ) and sufficient faculty members, it is one of the largest mechanical engineering in ACTCET. Over the years the department has future plans to built a reputation for outstanding teaching in the rural area, Nelvoy village with 100% infrastructure.

The department houses excellent experimental and computational facilities for CAD and other activities. The areas of interest to faculty members span thermal engineering , fluid mechanics, heat transfer, hydro turbines, IC engines, combustion studies, refrigeration and air conditioning, manufacturing, metrology, metal cutting, computer aided manufacturing, precision engineering and instrumentation. Faculty members are engaged in active research with partners from Government establishments and industry



LRC 01

Mechanical Divisions and Laboratories

Engineering Practices Laboratory

Back To Top

Facilities
  1. Arc welding transformer with cables and holders.
  2. Welding booth with exhaust facility.
  3. Welding accessories like welding shield, chipping hammer, wire brush, etc.
  4. Oxygen and acetylene gas cylinders, blow pipe and other welding outfit.
  5. Centre lathe.
  6. Hearth furnace, anvil and smithy tools.
  7. Moulding table, foundry tools.
  8. Power Tool- Angle Grinder.
  9. Study-purpose items- centrifugal pump, air-conditioner.

Computer Aided Drafting and Modeling Laboratory

Back To Top

Facilities
  1. Hardware, with graphics facility (AUTOCAD 2010)
  2. Licensed software for Drafting and Modeling
  3. Laser Printer - Plotter to print / plot drawings

Manufacturing Technology Lab

Back To Top

Facilities
  1. Centre Lathe with Tools and accessories
  2. Welding
    1. Arc welding machine
    2. Gas welding machine
    3. Brazing machine
  3. Sheet Metal Work facility
    1. Hand Shear 300mm
    2. Bench vice
    3. Standard tools and calipers for sheet metal work
  4. Sand moulding Facility
    1. Moulding Table
    2. Moulding boxes
    3. Moulding Tools and patterns
  5. Plastic Moulding
  6. Injection Moulding Machine

Fluid Mechanics and Machinery Lab

Back To Top

Facilities
  1. Orifice meter setup
  2. Venturi meter setup
  3. Rotameter setup
  4. Pipe Flow analysis setup
  5. Centrifugal pump/submergible pump setup
  6. Reciprocating pump setup
  7. Gear pump setup
  8. Pelton wheel setup
  9. Francis turbine setup
  10. Kaplan turbine setup

Manufacturing Technology Lab

Back To Top

Facilities
  1. Centre Lathes
  2. Turret and Capstan Lathes
  3. Horizontal Milling Machine
  4. Vertical Milling Machine
  5. Surface Grinding Machine.
  6. Cylinderical Grinding Machine
  7. Shaper.
  8. Slotter .
  9. Planner.
  10. Radial Drilling Machine
  11. Tool Dynamometer
  12. Gear Hobbing Machine
  13. Tool Makers Microscope

Strength Of Materials Lab

Back To Top

Facilities
  1. Universal Tensile Testing machine with double 1
  2. Shear attachment – 40 Ton Capacity
  3. Torsion Testing Machine (60 NM Capacity) 1
  4. Impact Testing Machine (300 J Capacity) 1
  5. Brinell Hardness Testing Machine 1
  6. Rockwell Hardness Testing Machine 1
  7. Spring Testing Machine for tensile and compressive loads (2500 N) 1
  8. Metallurgical Microscopes 3
  9. Muffle Furnace (800 °C)

Computer Aided Machine Drawing Laboratory

Back To Top

Facilities
  1. Computer System
    1. 17" Graphics Terminal
    2. Pentium IV Processor
    3. 80 GB HDD
    4. 512 MB RAM
    5. Advanced graphics accelerator
  2. Laser Printer
  3. Plotter (A2 size)

Thermal Engineering Laboratory

Back To Top

Facilities
  1. I.C Engine – 2 stroke and 4 stroke model.
  2. Red Wood Viscometer.
  3. Apparatus for Flash and Fire Point.
  4. 4-stroke Diesel Engine with mechanical loading.
  5. 4-stroke Diesel Engine with hydraulic loading.
  6. 4-stroke Diesel Engine with electrical loading.
  7. Multi-cylinder Petrol Engine.
  8. Single cylinder Petrol Engine .
  9. Data Acquisition system with any one of the above engines .
  10. Steam Boiler with turbine setup .

Dynamics Laboratory

Back To Top

Facilities Device/equipments
  1. Cam analyzer.
  2. Motorised gyroscope.
  3. Governor apparatus - Watt, Porter, Proell and Hartnell governors.
  4. Whirling of shaft apparatus.
  5. Dynamic balancing machine.
  6. Static and dynamic balancing machine.
  7. Vibrating table.
  8. Vibration test facilities apparatus.
  9. Gear Model.
  10. Kinematic Models to study various mechanisms.
  1. Tachometers – Contact and non contact.
  2. Dial gauge.
  3. Stroboscope.
  4. Accelerometers – Vibration pickups.
  5. Displacement meters.
  6. Oscilloscope.
  7. Vibration Shaker.
  8. F.F.T. Analyzer.
  9. Dynamic Balancing Machine.

Metrology & Measurements Laboratory

Back To Top

Facilities
  1. Micrometer Vernier
  2. Caliper Vernier
  3. Height Gauge Vernier depth Gauge
  4. Slip Gauge Set Gear
  5. Tooth Vernier
  6. Sine Bar
  7. Sine Center
  8. Bevel Protractor
  9. Floating Carriage Micrometer
  10. Profile Projector / Tool Makers
  11. Microscope Mechanical / Electrical / Pneumatic Comparator
  12. Autocollimator
  13. Temperature Measuring Setup
  14. Displacement Measuring Setup
  15. Force Measuring Setup
  16. Torque Measuring Setup
  17. Vibration / Shock Measuring Setup

CAD/CAM Laboratory

Back To Top

Hardware Software
  1. Computer Server .
  2. Computer nodes or systems (High end CPU with atleast 1 GB main memory) networked to the server.
  3. A3 size plotter.
  4. Laser Printer.
  5. Trainer CNC Lathe.
  6. Trainer CNC milling.
  1. CAD/CAM Licensed software .
  2. CAM Licensed Software (CNC Programming and tool path simulation for FANUC / Sinumeric and Heiden controller).
  3. Licensed operating system.

Thermal Engineering Laboratory

Back To Top

Facilities
  1. Guarded plate apparatus.
  2. Lagged pipe apparatus.
  3. Natural convection-vertical cylinder apparatus.
  4. Forced convection inside tube apparatus.
  5. Pin-fin apparatus. Stefan-Boltzmann apparatus.
  6. Emissivity measurement apparatus.
  7. Parallel/counter flow heat exchanger apparatus.
  8. Single/two stage reciprocating air compressor.

Refrigeration and Air Conditioning Laboratory

Back To Top

Facilities
  1. Refrigeration test rig.
  2. Air-conditioning test rig

Curricular Activities

Back To Top

  • Arranged Industrial Visit for III year Mechanical Students at "Ashok Leyland-Chennai"

  • Arranged Industrial Visit for IV year Mechanical Students at "IG CORK-Chennai"

  • Arranged Industrial Visit for II year Mechanical Students at " JEPPIAR FURNACE-Chennai"
